Acson RCM 25 D User Manual

HEAT PUMP (R22)
MODEL INDOOR UNIT RCM 62CR
OUTDOOR UNIT
ALC 61CR
NOMINAL kcal/h 14110
COOLING W 16410
CAPACITY Btu/h
56000
NOMINAL kcal/h 14110
HEATING W 16410
CAPACITY Btu/h 56000
NOMINAL TOTAL POWER (COOLING) W 6195
NOMINAL TOTAL POWER (HEATING) W 5265
NOMINAL TOTAL CURRENT (COOLING) A 30.6
NOMINAL TOTAL CURRENT (HEATING) A
26.0
POWER SOURCE V/Ph/Hz 230 / 1/ 60
REFRIGERANT / CONTROL R22 / CAPILLARY TUBE - INDOOR (COOLING), OUTDOOR (HEATING)
AIR FLOW cfm / L/s
1550 / 732
HIGH 56
MED 53
LOW 46
FAN MOTOR 2 x 4 POLES x 80 W
RATED INPUT POWER W 338
RATED RUNNING CURRENT A 1.60
MATERIAL
S.I.G.C
DIAMETER mm/in 9.52 / 3/8
THICKNESS mm/in 0.35 / 0.014
MATERIAL
ALUMINIUM
THICKNESS mm/in 0.11 / 0.0043
ROW 4
FIN PER INCH 14
FACE AREA
m
2
/
ft
2
0.42 / 4.51
HEIGHT mm/in 285 / 11.2
DIMENSION WIDTH mm/in 1903 / 74.9
DEPTH mm/in 680 / 26.8
WEIGHT kg 85
CONTROL ROOM TEMPERATURE MICROCOMPUTER CONTROLLED THERMOSTAT
OPERATION
LCD WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
CONDENSATE DRAIN SIZE mm/in 19.05 / 3/4
AIR FILTER WASHABLE SARAN NET
PACKING HEIGHT mm/in 368 / 14.5
DIMENSION WIDTH mm/in 1984 / 78.1
DEPTH mm/in 760 / 29.9
POWER SOURCE V/Ph/Hz 230 / 1 / 60
COMPRESSOR TYPE SCROLL
CAPACITOR µF 70
LOCK ROTOR AMP. A 144.0
RATED RUNNING CURRENT (COOLING) A
27.3
RATED RUNNING CURRENT (HEATING) A 22.7
RATED INPUT POWER (COOLING) W 5500
RATED INPUT POWER (HEATING) W 4570
PROTECTION DEVICE OVERLOAD PROTECTION / HI PRESSURE SWITCH
POWER SOURCE V/Ph/Hz 230 / 1 / 60
FAN TYPE / DRIVE
PROPELLER / DIRECT
BLADE MATERIAL
GLASS R. ACRLY STYLENE RESIN
DIAMETER mm/in 600 / 24
RATED RUNNING CURRENT A 1.7
MOTOR OUTPUT W
160
RATED INPUT POWER W 357
MATERIAL S.I.G.C
DIAMETER mm/in
9.52 / 3/8
THICKNESS mm/in 0.35 / 0.014
MATERIAL ALUMINIUM (CORRUGATED)
THICKNESS mm/in 0.127 / 0.005
ROW 3
FIN PER INCH 14
FACE AREA
m
2
/
ft
2
0.84 / 9.04
HEIGHT mm/in 850 / 33.5
DIMENSION WIDTH mm/in 1030 / 40.6
DEPTH mm/in 460 / 18.1
WEIGHT kg
108
MATERIAL ELECTRO GALVANIZED MILD STEEL
CASING THICKNESS mm/in 1.0 - 2.3 (0.0393 -0.0905)
FINISHING EPOXY POLYESTER POWDER COATING
SOUND PRESSURE LEVEL dBA 61
TYPE FLARE VALVE
SIZE LIQUID mm/in 12.7 / 1/2
GAS mm/in 19.05 / 3/4
PACKING HEIGHT mm/in 1016 / 40.0
DIMENSION WIDTH mm/in 1178 / 46.4
DEPTH mm/in
602 / 23.7
COMPRESSORFANCOIL
TUBEFIN
PIPE
INDOOR UNIT
FAN
SOUND LEVEL (dBA)
COIL
TUBEFIN
OUTDOOR UNIT
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
b) HEATING - 21.1°C DB / 15.6°C WB INDOOR AND 8.3°C DB / 6.1°C WB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
26.7°C DB / 19.4°C WB INDOOR AND 46.1°C DB OUTDOOR
b) HEATING - 21.0°C DB INDOOR AND -8.3°C DB / -9.4°C WB OUTDOOR TO
26.7°C DB INDOOR AND 23.9°C DB / 18.3°C WB
Abbreviation
S.B.C. - SEAMLESS BARE COPPER
S.I.G.C - SEAMLESS INNER GROOVE COPPER
8
