0-2
1.2 PHYSICAL DESCRIPTION
1. Ethernet Port
The IP device connects to the Ethernet via a standard RJ45
connector. Supporting NWAY, this IP device can auto detect the
speed of local network segment (10Base-T/100Base-TX
Ethernet).
2. Power Input
If your power input is DC12V. Please follow the description on
the connector to connect to power.
3. Reset Button
Step 1: Switch off IP device by disconnecting the power cable
Step 2: Press and continue to hold the Reset Button. Reconnect
PIN NAME DESCRIPTION
1 12V DC Power Input
2 GND Ground Pin
