Hardware Manual
21
Waterproof Solution with Conduit
This section describes the procedures to waterproof the cabling connections using the bundled
conduit gland and flexible conduit. This is the recommended solution if an exterior-grade Ethernet
cable is not available or when other cables, such as power adapter, DI/DO devices, etc., will be
connected to the camera.
If other connectors will be connected or a memory card will be installed, the camera module must
be removed from the housing first. See How to Remove the Camera Module on page 34.
1. Prepare the following materials for waterproof installation:
Conduit Gland
(included in the camera package)
Flexible Conduit
1/2" Trade size
(not included in the package)
For use with 1/2” flexible conduit
Network Cable
CAT 5 or CAT 6
(not included in the package)
To Next Page
