ACTi INR-340 - Hardware Installation; Front Panel; Rear Panel

Standalone NVR Quick Installation Guide 3
AT A GLANCE
StorageDiskBaysx5
System Disk
Power Button
Power Status LED Indicator
USB Ports x 2
Front Panel
Rear Panel
HARDWARE INSTALLATION
This package contains:
• INR x 1
• HDD Tray Keys Pack x 1
• Disk Screws Pack x 1
• Power Cord x 1
UNPACK
USB Ports x 4
VGA Port
LAN1 Port LAN2 Port
AC Power Connector
This package contains:
• INR x 1
• HDD Tray Keys Pack x 1
• Disk Screws Pack x 1
• Quick Installation Guide x 1
• Power Cord x 1
• Universal Converter x 1
• Warranty Card x 1
eSATA Port
HDMI Port / Display Port
Display Port
Line-in
Line-out
Mic-in
