TCD-2100 Hardware User’s Manual
12
Product Specification
TCD-2100
Compression H.264/ MPEG-4/ MJPEG simultaneous dual streams selectable
Picture Resolution
Full D1 (720x480 in NTSC, 720x576 in PAL)
CIF (352 x 240 in NTSC, 352 x 288 in PAL)
QCIF(160 x 112 in NTSC, 176 x 144 in PAL)
Bit Rate 28K ~ 6M bps
Image Frame Rate
30fps at full D1 resolution (NTSC)
25fps at full D1 resolution (PAL)
Video Input Composite Input CVBS, 1.0Vp-p with 75Ω loading, BNC Connector
Video Output Composite Output N/A
Compression N/A
Audio Line Input N/A
Compression N/A
Audio Line Output N/A
Input 1, TTL, Terminal Block
Output 1, TTL, Terminal Block
Remote Control Serial Port
RS-485: Half Duplex, Terminal Block
RS-422: Full Duplex, Terminal Block
RS-232: Full Duplex, Terminal Block
Reset Button Factory Default
LED System status
Ethernet Port Ethernet(10/100 Base-T), RJ45 Connector
Protocol
TCP, UDP, IP, HTTP, DHCP, PPPoE, RTP, RTSP,IPv6, FTP, SMTP, DNS, DDNS,
NTP, ICMP, IGMP, ARP
Web Browser Microsoft Internet Explorer 6.0 or above
SDK ACTi SDK-10000
PTZ protocol*
Pelco-D,Pelco-P V1 and V2, Dynacolor, Sony VISCA, American Dynamics
Security Password Protection: Configured by the Administrator
Operating Temperature
Power Requirement DC12V±10%
Power Consumption 3.6 W
Dimensions (WxHxD)
103 mm x 28.5 mm x 76 mm
(4.06" x 1.12" x 2.99")
Weight 195 g(0.43 lb)
Approvals Certificate CE, FCC
