S001964 10ft Trampoline
AssemblyInstructions(cont)
Step 5
ConnecttheUpperPole(12)totheLowerPole(11)byinsertingtheLowerPole(11)intothebaseof
theUpperPole(12)andsecuringitinplaceusingthelockingpins.
Repeattheaboveinstructionforallremaining5xUpperPoles(12)and5xLowerPoles(11).
SlideaPoleSleeve(15)overeachofthe6xenclosurepolesassembledinthepreviousinstruction.
Attachthe6xenclosurepolestotheframebyinsertingthemintotheupperpartofthe6xT-Joints(9)
and secure them into place using the locking pins.
11
12
