LM SERIES WALL CONTROLLER APPLICATION MATRIX
WALL CONTROLLERS
(See Notes Below)
MODELS LM7 LM7-D LM24W C7-4 LM-ZC LM-ZS
LM-RS
AERSS
MANUAL
INPUT
*
REMOTE
ON / OFF
*
SRE091C / SRG091E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRA101C / SRG101E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRA131C / SRG131E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRA133C / SRG131E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRD131C / SRV131E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRA151C / SRG151E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRA153C / SRG151E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRD151C / SRV151E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRD151C / SRM151E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRA171C / SRG171E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRA173C / SRG171E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRD173C / SRV171E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRD173C / SRM171E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRD191C / SRV191E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRD191C / SRM191E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRA203C / SRG201E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRD203C / SRV201E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRD203C / SRM201E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRA233C / SRG231E STD N/A OPT OPT N/A N/A OPT OPT OPT
SRD233C / SRV231E N/A STD OPT N/A N/A N/A OPT N/A OPT
SRD233C / SRM231E N/A STD OPT N/A OPT OPT N/A N/A OPT
SRA260C / SRA260E STD N/A OPT OPT N/A N/A OPT OPT OPT
NOTES: These Wall Controllers are Low Voltage Inputs only.
Usage of 240V manual input will damage equipment and void warranty.
*
When using manual inputs, a 4 core 14/0.20 screened cable must be used between controller and PCB.
**
ON / OFF switching operation of air conditioning system from a remote location.
This is designed to work with Home / Building Automation System.
STD - Standard Supplied.
OPT - Optional, contact ActronAir Customer Care for your specifi c application requirement.

ActronAir LM7-D Specifications

General

Brand	ActronAir
Model	LM7-D
Category	Controller
Language	English
