To replace it: Loosen the five bolts.
Clean the air cleaner element by
blowing compressed air through it in
the opposite direction to normal air
flow. If you do not have access to
compressed air (such as a service
station), ask your Acura dealer to do
this service.
The air cleaner element should be
cleaned or replaced according to the
time and distance recommendations
in the maintenance schedule.
Unsnap the clamp, then remove
the intake air duct from the front
of the air cleaner housing.
Use a pair of pliers to slide back
the clamp on the breather tube
attached to the side of the housing.
The air cleaner element is inside the
air cleaner housing on the driver’s
side of the engine compartment.
Follow the replacement procedure
for removal and reinstallation.
1.
2.
3.
Air Cleaner Element
Maintenance
Cleaning (Severe Conditions)
Replacement
222
AIR CLEANER
HOUSING
BREATHER TUBE
INTAKE AIR DUCT
BOLTS
