Install the new bulb into the
socket.
Push the socket into the light
assembly and turn it clockwise
until it locks.
Testthelightstomakesurethe
new bulb is working.
Install the rear light assembly in
the body. Tighten the two screws.
Snap the covers back into position.
Remove the light assembly cover
by prying carefully with a cloth-
covered screwdriver in the
notches along the top edge. Then
pivot the cover out and down.
Remove the socket from the light
assembly by turning it one-quarter
turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Testthelightstomakesurethe
new bulb is working.
Put the socket back into the light
assembly and turn it clockwise to
lock it in place.
Place the cover back into the light
assembly. Push it up until it locks
in place.
1.
4.
5.
6.
2.
3.6.
7.
8.
9.
Lights
Maintenance
Replacing a High-mount Brake
Light Bulb
217
