Put the new spark plug into the
socket, then screw it into the hole.
Screw it in by hand so you do not
crossthread it.
Use a wrench to remove the two
bolts holding the ignition coil.
Remove the ignition coil by pulling
it straight out.
Remove the spark plug with
a five-eighths inch (16 mm) spark
plug socket.
Disconnect the wire connector
from the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
4. 5.
6.
7.
Spark Plugs
Maintenance
270
IGNITION COIL CONNECTOR
LOCK TAB
BOLTS
IGNITION COIL
