Press the fan control button
to increase the fan speed and airflow.
Press the button to
decrease it. The level of the fan
speed is shown in the display.
Press the temperature control
button to increase the temperature
of airflow, and the button to
decrease it. The temperature you
adjust is shown in the system display.
Pressing the AUTO button puts the
system in automatic operation mode.
The rear system automatically
adjusts the fan speed and airflow
levels to maintain the selected
temperature of the rear passenger
compartment. You will see AUTO in
the display.
Pressing the OFF button shuts off
the rear climate control system.
Each time you press the mode
button, the mode display changes
from to .
When is selected, air flows
from the upper vents on the back of
the center console.
When is selected, air flows
from the lower vents.
Fan Control
Mode Control
Temperature Control Automatic Operation
Climate Control System
176
０７／０７／０９ ０９：４５：２９ ３１ＳＴＸ６１０ ０１８１
