A child seat with a tether can be
installed in any seating position in
the back seat, using one of the
anchorage points shown above.
Since a tether can provide additional
security to the lap/shoulder belt
installation, we recommend using a
tether whenever one is required or
available.
Lift the anchor cover, then attach
the tether strap hook to the
anchor, making sure the strap is
not twisted.
Tighten the strap according to the
seat maker’s instructions.
After properly securing the child
seat with the lap/shoulder belt
(see page ), pivot the head
restraint down (see page ) and
route the tether strap over the
head restraint.
1.
2.
3.
22
156
Installing a Child Seat
Installing a Child Seat with a
Tether
Driver and Passenger Safety
51
COVER
ANCHOR
TETHER ANCHORAGE POINTS
TETHER STRAP HOOK
ANCHOR
