To replace the rear wiper blade:
1. Raise the wiper arm off the rear
window.
2. Slide the blade out of the wiper
arm.
3. Examine the new wiper blades. If
they have no plastic or metal
reinforcement along the back
edge, remove the metal
reinforcement strips from the old
wiper blade, and install them in the
slots along the edge of the new
blade.
WIPER ARM
BLADE
REINFORCEMENT
Wiper Blades
538
