10 of 25 BII 48865 (1303) © 2013 American Honda Motor Co., Inc. – All Rights Reserved.
• Fold back the adhesive backing from the
antenna as shown.
• Using isopropyl alcohol on a shop towel, clean
the windshield where the antenna will attach.
• Attach the antenna with masking tape. Adjust
the position of the antenna so there is equal
spacing on both sides.
Clean with
isopropyl alcohol.
ANTENNA
MASKING TAPE
HEADLINER
ANTENNA
Equal spacing on both sides.
• Carefully remove the adhesive backing from the
antenna, and attach the antenna to the
windshield. Press and hold the antenna firmly in
place for 30 seconds.
• Remove the masking tape.
30. Gently pull down the headliner, and tuck the antenna
cable under the headliner. Be careful not to crease
the headliner.
ADHESIVE
BACKING
(Remove.)
ANTENNA
MASKING
TAPE
(Remove.)
HEADLINER
ANTENNA
CABLE
ANTENNA
To Next Page
