9
ACURA ARX-06 GTP // USER MANUAL
WHEELSPIN / BRAKE LOCK INDICATOR LIGHTS
Two sets of LED lights are situated behind the steering wheel on the dash to quickly
communicate to the driver if any wheelspin or brake lockup is occurring. The left LED cluster
corresponds to the left wheels and the right cluster corresponds to the right wheels.
TRACTION CONTROL
When the clusters light up all LEDs in blue the Traction Control system is intervening to reduce wheelspin.
Severe cases of wheelspin and TC system activation will produce a solid blue light and the lights will begin flashing
for less amounts of TC intervention.
ACURA ARX-06 GTP // DASH PAGES
RIGHT COLUMN
BAL Current Brake Bias setting
F REM Amount of fuel remaining
ARB F/R Currently selected Front (blue) and Rear (red) ARB settings
F LAP Amount of fuel used in the previous lap
POIL Engine Oil Pressure
PWAT Engine Water Pressure
CENTER COLUMN
Gear Indicator Currently selected gear, shown in the center of the display
Tire Pressures Live tire pressures, shown below the Gear Indicator for each tire
Tire Surface
Temperature
Live surface tire temperature for each tire
