Put a new washer on the filler bolt,
then reinstall the filler bolt. Tighten
it securely. Tightening torque:
The differential should be drained
and refilled with new fluid according
to the time and distance
recommendations in the
maintenance schedule.
Check the fluid level with the
differential at normal operating
temperature and the vehicle sitting
on level ground. Remove the
differential fluid filler bolt and
washer and carefully feel inside the
bolt hole with your finger. The fluid
level should be up to the edge of the
bolt hole. If it is not, slowly add
VTM-4 Differential Fluid until it
starts to run out of the hole.
Maintenance
Differential Fluid
272
FFIILLLLEERR BBOOLLTT
CCOORRRREECCTT LLEEVVEELL
33 lbf·ft (45 N·m , 4.6 kgf·m)
