uuReplacing Light BulbsuBrake Light and Rear Turn Signal Light Bulbs
Brake Light and Rear Turn Signal Light Bulbs
When replacing, use the following bulbs.
1. Remove the cover.
u Starting at the bottom, carefully pull the
cover straight out, working upward until
all pins are removed from their
grommets.
u The grommets should remain in the
body.
2. Use a Phillips-head screwdriver to remove
the bolts.
3. Pull the light assembly out of the rear pillar.
Brake Light: 21 W
Rear Turn Signal Light: 21 W
20 ACURA MDX-31TZ56600.book 594 ページ ２０１９年４月２４日 水曜日 午後５時４４分
