Remove the bulb by pushing it in
slightly and turning it
counterclockwise.
Install the new bulb into the
socket.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
The bulbs for the taillights, tail/
stoplights, rear turn signals, and
back-up lights are behind the trunk
liner.
Pull the top edge of the trunk liner
out from under the rubber seal.
Remove the plastic clips holding
the trunk liner by first unscrewing
the center pin. Then pull the clip
out of the liner with a button puller
or your fingers.
On the passenger’s side, loosen
the 6 mm stopper bolt using the
tool in the tool kit and pivot the
CD changer downward as shown
before you start working on the
trunk liner.
Determinewhichbulbinthe
taillight assembly is burned out.
2.
3.
4.
5.
1.
2.
3.
CONTINUED
Lights
Replacing the Rear Bulbs
Maintenance
157
STOPPER BOLT
