Airbag System Components
Additional Information About Your Airbags
24
(1)
(2)
(3)
(4)
(5)
(8)
(7)
(10)
(11)
(9)
(6)
(4)
(8)
(10)
(5)
(11) Occupant Position Detection System (OPDS) Sensors
(1) Driver’s Airbag
(2) Front Passenger’s Airbag
(3) Control Unit
(4) Front Seat Belt Tensioners
(5) Side Airbags
(6) Driver’s Seat Position Sensor
(7) Front Passenger’s Weight Sensors
(8) Front Impact Sensors
(9) Passenger Airbag Off Indicator
(10) Side Impact Sensors (First)
