Push the edge of the cover on the
blade assembly until the other side
of edge is pivoted out, and remove
the cover.
Disconnect the blade assembly
from the wiper arm by removing
the two screws from the arm.
Adjust the windshield wiper arms
to the winter position by holding
bothwiperarmsasshowninthe
illustration at the same time (see
page ). Raise the wiper arms
off the windshield.
Check the condition of the wiper
blades at least every 6 months.
Replace them if you find signs of
cracking in the rubber, areas that are
getting hard, or if they leave streaks
and unwiped areas when used.
2.1.
3.
103
Wiper Blades
Maintenance
323
COVER
SCREWS
WIPER ARMS
HOLDING LOCATIONS
Do not open the hood when the wiper
arms are raised, or you will damage
the hood and the wiper arms.
To Next Page
