ArrowMAX 2.0 ’
7
ENGLISH
Acuva systems are designed for ease of installation. The ArrowMAX 2.0 system requires a flow
restrictor to maintain a constant flow rate.
Item No. Description
Quantity
1 ½” PEX to ¼” OD Tee/Shut-o Valve 1 0
2 ⁄” OD Tube 1 1
3 Filter Clip 2 2
4 In-line filter 1 1
5 ArrowMAX 2.0
2)
1 1
6 Flow Restrictor 1 1
7 Power Plug Cable 1 1
8 Smart Faucet 1 0
2)
Item No. 5 (ArrowMAX 2.0) is certified against NSF 55 and NSF 372 - other installation components
are not included as part of the certification.
Installation with Smart Faucet Installation without Smart Faucet
INSTALLATION GUIDE
