5 .THE MIDI IN/ OUT CONNECTOR
The MIDI OUT connector transmits MIDI data
generated by your instrument .Most MIDI key-
boards (including your instrument, of course)
transmit note information via this connector. If the
MIDI OUT connector is connected to the MIDI IN
connector of a second keyboard. The result is that
you can effectively play two instruments at once.
MIDI OUTMIDI OUT
Tone GeneratorTone Generator
MIDI OUTMIDI OUT
YOUR INSTRUMENTYOUR INSTRUMENT
66
