Adam A77X User Manual

8
Please make sure that there are no obstacles in the way from the monitor to your ears.
You should be able to see the speakers completely.
4.1 Vertical set up
The AX-series have been designed for
a vertical set up (except the A77X). The
speakers must be positioned on a solid
surface or a stand. Please note that
vibrating parts of nearby objects can
mask the sound.
4.2 Horizontal set up
If you choose to use your speakers in horizontal position as indicated below, please
make sure that the set up is mirrored/symmetrical, i.e. that the tweeters both face
either the outwards or inwards. This is crucial for a precise stereo signal.
4. Speaker Placement
A3X
A3X
A3X
A3X
A3X
A3X
like
this:
or like
that:

Adam A77X Specifications

General

Type	Active Studio Monitor
Frequency Response	38 Hz - 50 kHz
Amplifier Power Woofer	100 W
Input Connectors	XLR, RCA
Tweeter	X-ART
Amplifier Power Tweeter	50 W
Input Impedance	10 kOhm
Woofer	7 inch Carbon/Rohacell/Glass Fiber
Weight	28.2 lbs (12.8 kg)
