Adam Sub7 User Manual

15
Sub7 Manual / English
12 . Technical Data
1 = long term IEC 265-8-Wrms / 10 min
2 = nominal IEC 265-8 = Peak Power 5 µsec
Sub7
Subwoofer 178 mm / 7“
Voice coil ø 38 mm / 1.5“
Woofer material coated paper
Built-in amplifiers 1
Subwoofer channel
1/2
140 W / 210 W
EQ 80 Hz -60 to +6 dB
Frequency response 32 Hz - 150 kHz
THD >60 Hz ≤ 1%
Max. peak ≥ 107 dB
Crossover frequency 50 - 150 Hz
Inputs XLR / RCA
Input impedance 10 kΩ
Weight 8 kg / 17.6 lb.
Height x Width x Depth 370 x 200 x 280 mm / 14.5“ x 8“ x 11“
Warranty 5 years
Operating temperature 0° C to 40° C (32° F to 104° F)
Storage temperature -30° C to 70° C (-22° F to 167° F)
Humidity Max. 90 % not condensing

Adam Sub7 Specifications

General

Subwoofer type	Active subwoofer
Subwoofer frequency range	32 - 150 Hz
Subwoofer crossover frequencies	50 - 150 Hz
Product color	Black
XLR in	Yes
