25
Obtaining SCSI Cables
Internal Cables
Internal Connector Diagrams
Table 3. Internal Cables
Description
Cable Model
Number Ordering Name
50-pin with connector for 4 SCSI devices
+ SCSI card (1.5 m)
1100 ACK-INT5
68-pin with connectors for 4 SCSI
devices + SCSI card (1.1 m)
1200 ACK-W2W-E
Figure 14. Low-density 50-pin
Figure 15. High-density 68-pin
