Adaptec 2940UW - External Connector Diagrams; Cabling Examples

22
SCSI Card 2940UW Pro User’s Reference
External Connector Diagrams
Cabling Examples
Figure 3. High-density 68-pin
Figure 4. High-density 50-pin
Figure 5. Low-density 50-pin
Figure 6. DB25-pin
SCSI Card 2940UW Pro
Fast/Wide
Ultra
Peripheral
(Terminated)
High-density 68-pin Internal Ultra SCSI Cable
Fast/Wide
Ultra
Peripheral
Fast/Wide
Ultra
Peripheral
Figure 7. Connecting Fast/Wide Ultra Internal SCSI Devices
