Appendix G: Technical Specifications ● 94
Environmental Specifications
Note: Forced airflow is recommended, but not required.
DC Power Requirements
Current Requirements
Ambient temperature without forced
airflow
0°C to 40°
C
Ambient temperature with forced
airflow of atleast 200 CFM
0°C to 55°
C
Relative humidity 10% to 90%, noncondensing
Altitude up to 3,000 meters
PCI, PCI-X, PCIe Ripple and noise 50mV peak-to-peak (max)
PCI, PCIX DC Voltage 5V ±5%, 3.3V ± 10%
PCIe DC Voltage 3.3V ± 10%
Adaptec Model Maximum Current (A)
ASC-58300 0.56A
ASC-48300 1.322A
ASC-44300 .445A
AAR-1430SA 1.5A
AAR-1420SA 1.5A
AAR-1220SA 1.5A
AAR-1225SA 1.5A
