ADB 2721W - Digital Set Top Box; Front Panel Overview; Back Panel Connections

DIGITAL SET TOP BOX
BACK PANEL
Video / Audio Out (RCA Yellow, White, Red) – These connections are ideal for VCR’s and older TV’s.
The audio ports can be used independently if other video connections have been used.
Component Video Out (Y,Py,Pb) – Component video cables can be used for high quality signals to either
HD or non-HD TV’s.
HDMI Out – HDMI is the highest fidelity HD connection that contains both audio and video signal.
Use for HDTV’s.
Ethernet – Connects the Ethernet cable from your home network or modem.
USB – Port for a USB device to allow for users to Pause, Play, and Rewind current shows.
SPDIF Audio Out - Connects Optical cables to send a digital audio signal to a surround-sound receiver
or other digital audio devices.
Power In – Connects to the supplied adapter to power unit.
ON/OFF Switch – Power switch to power cycle or reboot device manually.
Power – (Green) Lit when digital box is on.
(Red) Lit when digital box is off.
Record – (Red) Lit when recording with DVR functionality.
(Only available with DVR Service)
HD – (Green) Lit when viewing an HD program.
USB Port – Port for a USB storage device to allow users
to Pause, Play, and Rewind current shows.
SD Card Slot – Slot for an SD card to allow users to Pause,
Play, and Rewind current shows.
