ADC Soneplex Broadband System - Page 166

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-143
© 2000, ADC Telecommunications, Inc.
DLP-541
Page 14 of 16
9700-A
Low Speed Loopback Status/Commands
Group: 5 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
======== ========= ========
COMMANDS:
Loopback: N/A N/A
STATUS:
Unit Type: DLX NONE NONE
+---------+
| |AIS
---------------> | --+ +-> |---------------------------------------------------->
NETWORK | | | CUSTOMER
DS1 | | | DS1
|| |
<--------------- | <-+ +-- |<---------------------------------------------------
|net cust |
+---------+
Press CONTROL-A For Assistance
Figure 541-11b. DLX Network Loopback Screen
14848-A
Low Speed Loopback Status/Commands
Group: 7 DS1#: 3
Unit Location - LOCAL REPEATER REMOTE
======== ========= ========
COMMANDS:
Loopback: N/A N/A
STATUS:
Unit Type: DLX NONE NONE
+---------+
LPBK RQ> | |AIS
---------------->|--+ +->|---------------------------------------------------->
NETWORK | | | CUSTOMER
DS1 | | | DS1
| | |
<----------------|<-+ +--|<----------------------------------------------------
<LPBK RQ |net cust|
+---------+
Press CONTROL-A For Assistance
Figure 541-11c. DLX SEND LPBK Screen
