ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-144
© 2000, ADC Telecommunications, Inc.
DLP-541
Page 15 of 16
Low Speed Loopback Status/Commands
Group: 1 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
========== ========== ==========
COMMANDS:
Loopback: N/A N/A
STATUS:
Unit Type: RLX NONE NONE
+---------+
| |
-------------->|--+ +->|----------------------------------------------------->
NETWORK | | | CUSTOMER
DS1 | | | DS1
| | |
<--------------|<-+ +--|<-----------------------------------------------------
|net cust|
+---------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
9493-C
AIS
Figure 541-12a. RLX Customer Loopback Screen
Low Speed Loopback Status/Commands
Group: 1 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
========== ========== ==========
COMMANDS:
Loopback: N/A N/A
STATUS:
Unit Type: RLX NONE NONE
+---------+
| |
-------------->|--+ +-->|----------------------------------------------------->
NETWORK | | | CUSTOMER
DS1 | | | DS1
| | |
<--------------|<-+ +---|<-----------------------------------------------------
|net cust|
+---------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
9494-B
AIS
Figure 541-12b. RLX Network Loopback Screen
