ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-167
© 2000, ADC Telecommunications, Inc.
DLP-549
Page 3 of 3
18. If you made changes to port configurations, log off and then log back on to the system to
implement the changes.
Reference:
DLP-564 Craft Interface System Logoff
Reference:
DLP-526 Craft Interface System Logon
Stop! You have completed this procedure.
6142-A
SERIAL PORT CONFIGURATION
Port Label CRAFT PORT 1/2 PORT 3
======== ======== ========
Application : CRAFT TBOS X.25
Baud Rate : 9600 2400 NOT APPL
Parity : NONE ODD NOT APPL
Data Bits : 8 8 NOT APPL
Stop Bits : 1 2 NOT APPL
Flow Control : NONE NONE NOT APPL
Keyboard Timeout: 30 MIN NOT APPL NOT APPL
TBOS CONFIGURATION
TBOS Mode : EXPANDED
Display 1 Response Address: NOT APPL
Display 2 Response Address: NOT APPL
Press CONTROL-A For Assistance
Figure 549-1. Serial Port Configuration Screen
Table 549-1. Serial Port Default Settings
COMMUNICATION
PARAMETER
CRAFT PORT
(DCE)
PORT 1/2
(DTE)
PORT 3
(DTE)
Application CRAFT TBOS X.25
Baud Rate 9600 2400 Not Applicable
Parity NONE ODD Not Applicable
Data Bits 8 8 Not Applicable
Stop Bits 1 2 Not Applicable
Flow Control NONE NONE Not Applicable
Keyboard Timeout 30 MIN NOT APPL Not Applicable
Note:
For X.25 Port configuration, see DLP-558.
