ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-233
© 2000, ADC Telecommunications, Inc.
DLP-573
Page 2 of 6
HLX CONFIGURATION
1. HLX Unit Configuration
2. Loopback Configuration
Press CONTROL-A For Assistance
6765-A
Figure 573-1. HLX Configuration Menu
HLX LOOPBACK CONFIGURATION
Group: 6 Slot: 1 Circuit ID:
HLXC Activation Code : 1101001111010011
HLXC Programmable Lpbk : DISABLED
HLXR NID Loopback : UNIT SWITCH
HLXR Activation Code : 1100011101000010
HLXR Programmable Lpbk : DISABLED
HRX Activation Code : NOT APPL
HRX Programmable Lpbk : NOT APPL
Common Deactivate Code : 1001001110010011
Lpbk Timeout Disable Code: 1101010111010110
Lpbk Timeout Period : 30 minutes
Press CONTROL-A For Assistance
6697-B
Note: “Activation Code” is equivalent to “Programmable Code.”
Figure 573-2. HLX Loopback Configuration Screen (MPU V5.1 Without an HRX)
