DLP-573
Page 3 of 6
8113-A
HLX LOOPBACK CONFIGURATION
Group: 6 Slot: 1 Circuit ID:
HLXC Activation Code : 1101001111010011
HLXC Programmable Lpbk : DISABLED
HLXR NID Loopback : UNIT SWITCH
HLXR Activation Code : 1100011101000010
HLXR Programmable Lpbk : DISABLED
HRX Activation Code : 1100011101000001
HRX Programmable Lpbk : DISABLED
Common Deactivate Code : 1001001110010011
Lpbk Timeout Disable Code: 1101010111010110
Lpbk Timeout Period : 30 minutes
HLXR NID Loopback Switch Setting: ENABLED
Press CONTROL-A For Assistance
Note: “Activation Code” is equivalent to “Programmable Code.”
Figure 573-3. HLX Loopback Configuration Screen (MPU V5.1 With One HRX)
11389-A
HLX LOOPBACK CONFIGURATION
Group: 5 Slot: 1 Circuit ID:
HLXC Activation Code : 1101001111010011
HLXC Programmable Lpbk : DISABLED
ESF Inband Loopback : ENABLED
HLXR NID Loopback : UNIT SWITCH
HLXR Activation Code : 1100011101000010
HLXR Programmable Lpbk : DISABLED
HRX-1 Activation Code : 1100011101000001
HRX-2 Activation Code : 1100011101000010
HRX Programmable Lpbk : DISABLED
Common Deactivate Code : 1001001110010011
Lpbk Timeout Disable Code: 1101010111010110
Lpbk Timeout Period : 30 minutes
HLXR NID Loopback Switch Setting: ENABLED
Press CONTROL-A For Assistance
Note: “Activation Code” is equivalent to “Programmable Code.”
Figure 573-4. HLX Loopback Configuration Screen (MPU V5.2 With Two HRXs)
