ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-243
© 2000, ADC Telecommunications, Inc.
DLP-575
Page 5 of 5
6174-A
DS3MUX
DS3
NETWORK
DS1s
CUSTOMER
(LOW SPEED
MODULES)
RX
TX
TAU
:
:
:
:
6173-A
CUSTOMER
(LOW SPEED
MODULES)
DS3MUX
DS3
NETWORK
DS1s
RX
TX
TAU
:
:
:
:
Figure 575-3e. Drop: Network / Insert: Customer Figure 575-3f. Drop: Customer / Insert: Network
6172-A
DS3MUX
DS3
NETWORK
DS1s
CUSTOMER
(LOW SPEED
MODULES)
RX
TX
TAU
:
:
:
:
6171-A
DS3MUX
DS3
NETWORK
DS1s
CUSTOMER
(LOW SPEED
MODULES)
RX
TX
TAU
:
:
:
:
Figure 575-3g. Drop: Network / Insert: Network Figure 575-3h. Drop: Customer / Insert: Customer
Figure 575-3. TAU Drop/Insert Configurations, continued
