ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-250
© 2000, ADC Telecommunications, Inc.
TAD-101
Page 2 of 9
Table 101-1. Soneplex Broadband System (V5) Specifications, continued
PARAMETER SPECIFICATION REMARKS
DS3 Interface (DS3 MUX)
DS3 Input Level +5.7 dBm to –7.3 dBm
DS3 Transmit Power Level –1.8 to +5.7 dBm
Format Bipolar, Return to Zero
Impedance 75 ohms (nominal) With splitter/combiner
Line Code B3ZS
Line Rate 44.736 Mbps ± 20 ppm
Maximum Span 450 ft. to cross-connect facility
DS3 Interface (D1 DS3 MUX)
DS3 Input Level +5.7 dBm to –7.4 dBm
DS3 Transmit Power Level –1.8 to +5.7 dBm
Format Bipolar, Return to Zero
Impedance 75 ohms nominal With splitter/combiner
Line Code B3ZS
Line Rate 44.736 MHz ± 20 ppm
Maximum Span 450 ft. to cross-connect facility
DLX Module
Format Bipolar, Return to Zero Transparent to frame format
Input Impedance 100 ohms ± 5%
Input Signal Level 0 to –10 dB
Line Code AMI or B8ZS
Line Rate Standard DS1 code at
1.544 Mbps ± 200 bps (130 ppm)
Output Pulse Per GR-499-CORE, Issue 4 22 AWG ABAM
Output Signal Level 0 dB
C1 HLXC Module
Loop Loss <35 dB @ 196 kHz 135 ohm termination
Loop Types Two-pair, single or mixed gauges With or without bridged taps
Transmission:
Format Two 784 kbps full duplex pairs,
2B1Q modulation
Line Impedance 135 ohms nominal Balanced
Loop Power Output Voltage –132 ± 5 VDC
Return Loss >20 dB 40 kHz to 200 kHz
Total Signal Power +13.5 dBm ± 0.5 dBm
(continued)
