ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-249
© 2000, ADC Telecommunications, Inc.
TAD-101
Page 1 of 9
SPECIFICATIONS
Summary:
This TAD shows technical specifications for the Soneplex Broadband system with
MPU Version 5 software in Table 101-1 (System Specifications), Table 101-2 (DS3 MUX
Power), Table 101-3 (DLX Power), Table 101-4 (C1 HLXC Power), Table 101-5 (Version D and
E HLXC Power), Table 101-6 (ODS2 Power), Table 101-7 (A2 RLX Power), and Table 101-8
(Version B RLX / RLXIOR Power).
Table 101-1. Soneplex Broadband System (V5) Specifications
PARAMETER SPECIFICATION REMARKS
Dimensions
Chassis (H
×
W
×
D) 10
×
21.5
×
12 inches
(25.4
×
54.6
×
30.5 cm)
Environment
Operating Relative Humidity 5% to 95% No condensation
Operating Temperature –40
°
F to 149
°
F (–40
°
C to 65
°
C)
Storage Temperature –40
°
F to 158
°
F (–40
°
C to 70
°
C)
Power
Input Voltage Range –42.5 to –56.5 VDC A and B feed
Consumption (–48 VDC):
APU 7.5 watts maximum
MPU 5 watts maximum
DS3 MUX See Table 101-2 Per module
DLX See Table 101-3 Per module
C1 HLXC See Table 101-4
Version D and later HLXCs See Table 101-5
B1 HLXR
9.9 watts
Simplex current enabled
8.3 watts
Simplex current disabled
Version D and later HLXRs,
HLXR 3192
9 watts Simplex power enabled (D1, D2,
D2A-SP, D3, D3A, D3B HLXRs
only)
4 watts Simplex power disabled (D2A,
D4, D4A, D4B, and Version E
HLXRs; and HLXR 3192 only)
ODS2 See Table 101-6
A2 RLX See Table 101-7
Version B RLX / RLXIOR See Table 101-8
TAU 2 watts maximum
RTAU 8.2 watts maximum
Maximum Power Determined by configuration
(continued)
