DS1 PERFORMANCE MONITORING REPORTS
Group: 6 Circuit: 1 Site: LOCAL Report Type: 15-MINUTE
Circuit ID:
FCP SESL ESP SASP FCP-FE ESP-FE CSSP-FE
CVL LOSS SESP AISSP ESL-FE SESP-FE SEFSP-FE
PERIOD STATUS ESL CVP UASP CVP-FE UASP-FE
======== =========== ======= ======= ======= ======= ======== ======= ========
00:15 NE: NA 0 0 0 0 0 0 0
FE: NA 0 0 0 0 0 0 0
0 0 0 0 0
00:00 NE: NA 0 0 0 0 0 0 0
FE: NA 0 0 0 0 0 0 0
0 0 0 0 0
Page 1 of 1 Press CONTROL-A for assistance
Figure 102-1. DS1 15-Minute Performance Monitoring Report
6652-B
FCP SESL ESP SASP FCP-FE ESP-FE CSSP-FE
CVL LOSS SESP AISSP ESL-FE SESP-FE SEFSP-FE
PERIOD STATUS ESL CVP UASP CVP-FE UASP-FE
======== =========== ======= ======= ======= ======= ======== ======= ========
01/01/93 NE: NA 0 0 0 0 0 0 0
FE: NA 0 0 0 0 0 0 0
0 0 0 0 0
Page 1 of 1 Press CONTROL-A for assistance
DS1 PERFORMANCE MONITORING REPORTS
Group: 6 Circuit: 1 Site: LOCAL Report Type: DAILY
Circuit ID:
Figure 102-2. DS1 Daily Performance Monitoring Report
