TAP-102
Page 7 of 11
6653-B
FCP SESL ESP SASP FCP-FE ESP-FE CSSP-FE
CVL LOSS SESP AISSP ESL-FE SESP-FE SEFSP-FE
PERIOD STATUS ESL CVP UASP CVP-FE UASP-FE
======== =========== ======= ======= ======= ======= ======== ======= ========
00:15 NE: NA 0 0 0 0 0 0 0
FE: NA 0 0 0 0 0 0 0
0 0 0 0 0
00:00 NE: NA 0 0 0 0 0 0 0
FE: NA 0 0 0 0 0 0 0
0 0 0 0 0
01/01/93 NE: NA 0 0 0 0 0 0 0
FE: NA 0 0 0 0 0 0 0
0 0 0 0 0
Page 1 of 1 Press CONTROL-A for assistance
DS1 PERFORMANCE MONITORING REPORTS
Group: 6 Circuit: 1 Site: LOCAL Report Type: SUMMARY
Circuit ID:
Figure 102-3. DS1 Summary Performance Monitoring Report
HDSL PERFORMANCE MONITORING REPORTS
Group: 1 Circuit: 2 Loop: 1 Report Type: 15-MINUTE
Circuit ID:
PERIOD LOCN STAT FCP CVP ESP SESP SEFSP PA-H SNR-L
======== ==== ===== ======== ======= ======= ======= ======== ======= ========
00:00 NEND COMPL 0000 0017
FEND COMPL 0000 0017
CRP1 COMPL 0000 0017
RRP1 COMPL 0000 0017
23:45 NEND COMPL 0000 0017
FEND COMPL 0000 0017
CRP2 COMPL 0000 0017
RRP2 COMPL 0000 0017
23:30 NEND COMPL 0000 0017
FEND COMPL 0000 0017
CRP1 COMPL 0000 0017
RRP1 COMPL 0000 0017
23:15 NEND COMPL 0000 0017
Page 2 of 9 Press CONTROL-A for Assistance
6655-B
Figure 102-4. HDSL 15-Minute Performance Monitoring Report
