ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-310
© 2000, ADC Telecommunications, Inc.
TAP-102
Page 11 of 11
KEY
NEND means "PM information collected directly from incoming T1 signals, both at
local and remote sites".
FEND means "ESF PM information collected at the opposite end of spans from the
affected circuit and returned to the system via ESF datalink". The framing format
must be ESF in order for FEND information to be displayed.
10265-A
NEND
NEND
FEND
FEND
T1
T1
RLX
Span
Repeater
DS1
DS1
DS1
DS1
TO NETWORK TO CUSTOMER
LOCAL
(SITE = -1)
REMOTE
(SITE = -2)
Figure 102-11. RLX NEND and FEND Locations
