ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-59
© 2000, ADC Telecommunications, Inc.
DLP-516
Page 4 of 6
6181-B
RTAU
MODULE
1 to 28 HLXC UNITS
HSW
HSP
TAU
APU
MPU
MXPMXW
DS3 FAIL
RESET
LMPTST/
APS
LPBK
ENABLE
ONLINE
STATUS
APS LOCKOUT
FORCE
DS3 FAIL
RESET
LMPTST/
APS
LPBK
ENABLE
ONLINE
STATUS
APS LOCKOUT
FORCE
CR
MJ
MN
APU
ACO
PWR
HSKP
RMT
ALM
LMPTST
DISP RMT
STATUS
RESET
1-31-1 2-1 2-3 3-1 3-3 4-1 4-3 5-1 5-3 6-1 6-3 7-1 7-3
1-41-2 2-2 2-4 3-2 3-4 4-2 4-4 5-2 5-4 6-2 6-4 7-2 7-4
DS3 FAIL
DS3 FAIL
DS3 FAIL
DS3 FAIL
RTAU
DS3 MUX
UNITS
Figure 516-2. HLXC Module Locations
Table 516-1. DS1 Signal Routing
DS1
SIGNAL
GROUP-
SLOT
NUMBER
DS1
SIGNAL
GROUP-
SLOT
NUMBER
DS1
SIGNAL
GROUP-
SLOT
NUMBER
DS1
SIGNAL
GROUP-
SLOT
NUMBER
1 1-1 8 2-4 15 4-3 22 6-2
2 1-2 9 3-1 16 4-4 23 6-3
3 1-3 10 3-2 17 5-1 24 6-4
4 1-4 11 3-3 18 5-2 25 7-1
5 2-1 12 3-4 19 5-3 26 7-2
6 2-2 13 4-1 20 5-4 27 7-3
7 2-3 14 4-2 21 6-1 28 7-4
To Next Page
