the switched outlet is controlled by the front panel Power switch while the unswitched outlet carries AC current whenever the
GCA-510 is plugged into a live AC outlet. The power ratings for fries© outlets are as follows: 500 VA (equivalent to 500 watts)
maximum for the switched outlet and 800 VA (or watts) maximum for the unswitched outlet.
The switched outlet can be used for any system component that should be turned on or off when the GCA~510 is powered.
Tuners and CD players are the most likely candidates. The unswitched outlet is recommended for mechanical devices such as
a cassette deck where premature AC power interruptbn can result in damage to the drive assembly or for other source
components where a constant AC source is required to maintain internal settings.
9 ) After making sure that the “Level” control Ois turned completely down (counter-clockwise), plug the GCA-510 into an AC
outlet, preferably one that is NOT controlled by a wall switch or other device that may be turned off inadvertently. If you live in an
area supplied with 115 Volt AC, we strongly recommend use of ADCOM’s ACE-515 AC line enhancer and sequential switcher.
See your ADCOM dealer for details.
9) Use the “Power” switch Oto turn the GCA-510 on. The “Power Indicator LED” O will light.
10) Select a source for playback by rotating the “Listening” selector ©to the appropriate input position. You may select the same
source to record by rotating the “Recording” selector ©to the same input.
You can simultaneously select a totally different source for recording by simply selecting a different source with the “Record¬
ing” switch.
The GCA-510 will not allow a potentially destructive feedback condition even if you inadvertently set both the “Listening” and
“Recording” switches to the Tape position. In this case, the GCA-510 will automatically mute the recording output.
CARE AND FEEDING OF THE GCA-510
ADCOM has taken great care to assure that your GCA-510 is as flawless in appearance as it is electrically. The front panel is a
heavy-gauge, high grade anodized aluminum extrusion bead blasted for durability. The chassis, rear panel and top cover are
painted and baked heavy gauge steel.
If the outer cover or front panel becomes dusty or fingerprinted, please clean with a soft, lintless cloth, SLiGHTLY DAMPENED
with a very mild detergent solution.
DO NOT SPRAY OR USE LIQUIDS OF ANY KIND ON YOUR UNIT!
NEVER USE HARSH SCOURING POWDERS!
SERVICING
ADCOM’s Technical Service Department will be happy to answer all questions pertaining to the installation and operation of your
unit. In the unlikely event of difficulty, please contact us for prompt advice. If we can’t help you resolve the problem immediately,
we may refer you to an authorized repair agency, or authorize the return of your unit to our plant.
All written inquiries should be addressed to:
ADCOM Service Department
11 Elkins Road
East Brunswick, NJ.08816
USA
Telephone inquiries are welcomed from Monday through Friday between 9 AM and 4 PM, Eastern Time: (908) 390-1130
We’ll also be happy to answer FAX inquiries. Direct them to: (908) 390-9152 and include your FAX number for our response.
When inquiring about your unit, please include the serial number, the name of the dealer from whom you purchased the unit
and the date of purchase.
If we ask vou to return the unit to us for service, we will issue a specific Return Authorization number for your use. UNDER
nS cScUMsVaNCES should the unit be SHIPPED TO US WITHOUT PROPER AUTHORIZATION OR PACKED
IN ANYTHING OTHER THAN ITS ORIGINAL PACKING.
If the original packing has been lost, discarded or damaged, we will be happy to supply a replacement at a nommal
charge. Please mention your need when you call or write.
Alwavs ship PREPAID via UPS (United Parcel Service) or other appropriate carrier. FREIGHT COLLECT SHIPMENTS
WILL BE REFUSED. DO NOT SHIP VIA PARCEL POST as the packaging will not necessarily withstand handling by our
Postal Service.
