Adcom GFA-5300 Service Manual

1
INTRODUCTION
This service manual is intended to assist trained and qualified technical personnel in verifying the
performance of, adjusting, and repairing the ADCOM GFA-5300 amplifier. The procedures described here
are not intended for persons unfamiliar with the appropriate safety and test procedures.
TEST PROCEDURES
• All tests are performed with a 115V, low-distortion (less than 2% THD), AC-power source, 8-ohm
resistive load (except slew rate), and a signal source of not more than 600 ohms.
• An 80kHz low-pass filter is employed during THD distortion measurements.
• Signal-to-noise measurements are “A” weighted.
• Damping factor is measured by comparing the 1 watt output voltage with and without an 8 ohm load.
• Slew rate is measured with an inductive load, and is derived with a dual-time-based oscilloscope
reading the slope of a full power 5kHz square wave. DO NOT OPERATE THE AMPLIFIER AT
FULL-POWER SINE WAVE ABOVE 22kHz OR FULL-POWER SQUARE WAVE ABOVE 5kHz.
CORRECT BIAS ADJUSTMENT IS CRITICAL TO THE PERFORMANCE OF THIS AMPLIFIER.
MAXIMUM OUTPUT POWER, MINIMUM THD AND HEAT DISSIPATION ARE AFFECTED BY THE
BIAS SETTING AND MUST BE CORRECT TO MAINTAIN THE SONIC QUALITY AND LONGEVITY OF
THE AMPLIFIER.
BIAS ALIGNMENT
Prior to performing BIAS ALIGNMENT turn unit on and allow to idle with rated output (8 ohm) for
approximately 5 MINUTES before attempting adjustments
Bias Adjustment
Connect voltmeter across emitter resister R038 (R138 for right channel) and adjust R043 (R143 for right
channel) to read 20mV +/-2mV
DC Offset
Connect voltmeter across the speaker outputs and adjust R042 (R142 for right channel) to read 0mV +/-
10mV
WARNING
THERE ARE POTENTIALLY LETHAL VOLTAGES WITHIN THE GFA-5300 AMPLIFIER WHICH WILL
BE ACCESSIBLE ONCE ITS TOP COVER IS REMOVED. DO NOT ATTEMPT FAMILIARIZATION,
INSPECTION, OR ANY PROCEDURE WHATSOEVER UNLESS YOU HAVE DISCONNECTED THE
GFA-5300 FROM THE WALL AC OUTLET OR OTHER SOURCE OF AC POWER AND THE
POWER-SUPPLY CAPACITORS ARE COMPLETELY DISCHARGED. THESE INSTRUCTIONS ARE
PROVIDED FOR USE ONLY BY COMPETENT TECHNICAL PERSONNEL. DO NOT UNDERTAKE
ANY SERVICE PROCEDURES IN THE GFA-5300 UNLESS YOU ARE TECHNICALLY QUALIFIED TO
DO SO.
IMPORTANT
BEFORE PROCEEDING WITH ADJUSTMENTS, MAKE SURE AMPLIFIER IS AT ROOM
TEMPERATURE.

Adcom GFA-5300 Specifications

Power

power rating into 8 ohms	80 watts continuous average power per channel
power rating into 4 ohms	125 watts continuous average power per channel
power consumption - quiescent	100 VA
power consumption - maximum	720 VA
power consumption - 80 watts into 8 ohms	510 VA
power consumption - 125 watts into 4 ohms	720 VA
power supply voltage	115 VAC - 50/60 Hz

Distortion and Noise

IM distortion SMPTE 8 ohms	≤ 0.07%
IM distortion SMPTE 4 ohms	≤ 0.07%
IM distortion CCIF 8 ohms	≤ 0.035%
IM distortion CCIF 4 ohms	≤ 0.035%
THD + Noise at 80 watts into 8 ohms 20Hz	0.018%
THD + Noise at 80 watts into 8 ohms 1kHz	0.02%
THD + Noise at 80 watts into 8 ohms 10kHz	0.07%
THD + Noise at 80 watts into 8 ohms 20kHz	0.14%
THD + Noise at 125 watts into 4 ohms 20Hz	0.018%
THD + Noise at 125 watts into 4 ohms 1kHz	0.02%
THD + Noise at 125 watts into 4 ohms 10kHz	0.08%
THD + Noise at 125 watts into 4 ohms 20kHz	0.165%
signal to noise ratio (A weighted)	≥ 100 dB

Frequency and Gain

frequency response	+0, -0.25 dB from 10Hz to 20kHz
power bandwidth	3Hz to 130kHz
dynamic headroom into 4 ohms	2.1 dB
gain	29 dB

Input and Output

input sensitivity for 1 watt	0.1 volts
input sensitivity for 80 watts	0.9 volts
input impedance	49.9 kΩ
damping factor	≥ 350
rise time	1.8 µS

Weight and Dimensions

chassis dimensions	4 1/2” x 17” x 11 3/8” (105mm x 432mm x 289mm)
maximum dimensions	4 3/8” x 17” x 12 1/8” (111mm x 432mm x 308mm)
weight	22 lb. (10.0 kg)
weight, packed	25 lb. (11.3 kg)
