AddSecure Tor V, PDK-11606 17
APPENDIX – STATUS INDICATORS FOR TOR V
When powering up from an absence of voltage and before the tamper spring is
pushed down, table 1 applies. After the spring is pushed down and the signal
strength has been shown, table 2 applies. When warm booting the transmitter, the
signal strength is not displayed and table 2 applies directly.
LED function during power-up
1. LED A blinks at start. Other LEDs are off.
2. When the alarm transmitter has contact with the mobile network, LED A’s light is
solid.
3. If the alarm transmitter does not have contact with the mobile network or if the signal
strength cannot be measured, LED D blinks quickly.
4. The diodes indicate the signal strength of the mobile data network; see Table 1.
5. To return to normal mode, push down the opening tamper switch for five seconds or
put on the cover so that the switch for the opening tamper is pushed down.
6. The LEDs display as normal no matter whether the interference protection is affected.
Table 1 (signal strength).
