8
Mounting of the exhaust hose
Use only the hose provided
and attach exhaust hose
to the back of the air
conditioner.
FIG. 7
FIG. 10
WARNING!
The length of the exhaust hose
is specially designed according
to the specication of this
product. Do not replace or
extend it with an alternative
hose as this could cause the
unit to malfunction.
FIG. 9
The hose may be extended
from 300mm to 1500mm
but for maximum efciency
use the shortest length
possible.
FIG. 8
Avoid kinks and bends in
the exhaust hose as this will
cause expelled moist air to
build up causing the unit to
overheat and shut down.
Fig 7 & 8 show correct
position.
