6
ZW60-210531-Rev006-UM-en
MR Memory recall
Memory recall button. Displays the summed total weight from the
memory.
MC Clear memory
Memory clear button. Clears the summed total weight from the
memory.
SMPL
Piece
counting
mode
If the scale is in weighing mode, this button switches it to
counting mode.
If the scale is in counting mode, this button switches it back to
weighing mode
U.WT.
Manual
weight entry
Manual entry of a known weight value.
HI LIMIT
Maximum
value check
Recalls the stored maximum weight value in weighing mode or
the maximum quantity in counting mode. If the applied weight or
the applied quantity exceeds the maximum value, you will hear
an audible signal.
To enter the value, press and hold down this button for 3
seconds.
LOW
LIMIT
Minimum
value check
Recalls the stored minimum weight value in weighing mode or
the minimum quantity in counting mode. If the applied weight or
the applied quantity is smaller than the minimum value, you will
hear an audible signal.
To enter the value, press and hold down this button for 3
seconds.
0…9 / •
Manual entry
of values
Numeric buttons from 0 to 9 are used to manually enter values
such as unit weight or reference quantity.
C
Clear
manually
entered
values
Clears manually entered values.
5.3 Display symbols
The LCD display shows a value and the unit.
In addition, the display shows symbols for tare (TARE), gross weight (GROSS), zero position
(ZERO) and low bat-tery charge.
Symbol Meaning
Battery Battery charging required.
STABLE The weight shown on the display is stable.
ZERO The scale is in zero position.
GROSS The weight shown on the display is the gross weight.
NET The weight shown on the display is the net weight.
PCS The scale is in piece counting mode.
% The scale is in percent weighing mode.
M+ The display shows the result from the totaliser.
