ADENDORFF ML392 - Parts List

１９
10”(ML392 )&12”(ML393Q)PART LIST
NO.
SPECIFICATION
QTY
NO.
SPECIFICATION
QTY
1
Base stand
1
46
Locking plate
1
3
Small cover plate
2
47
Change-over plate
1
4
Right cover plate
1
48
Nut M6X12
2
5
Support sleeve
1
49
Thicknessing table assembly
1
11
Support base
4
50
Lifting tube
1
12
Right cutter block support
1
51
Oriented body
1
13
Left cutter block support
1
52
splint
1
14
Front adjusting block
1
53
Gear case assembly
1
15
BACK adjusting block
1
54
mandril
1
16
Front locking block
1
55
Block
1
17
Back locking block
1
56
Block
1
18
In-feed table
1
57
Locking bar assembly
1
19
Out-feed table
1
58
Wheel assembly
1
20
Adjusting axle
2
60
Pointer
1
21
Apron
2
61
Depth scale
1
22
Locking handle assembly
2
62
Washer
1
23
Eccentric bush
2
63
Thicknesser table
1
24
Screw M8X8
3
64
Apron
4
25
Kick block
20
66
Gear box
1
26
Turning axle
1
67
Helical gear
1
27
Support axle
2
68
Guide screw
1
28
Nut M10
14
69
Gear axle
1
30
Feed scale
1
70
Bush
1
31
Adjusting wheel
2
72
Locking handle
1
32
Locating plate
1
74
Control handle assembly
1
33
Feed pointer
1
75
Chain wheel assembly
1
35
Hex bolt M10X60
2
76
Chain wheel assembly
1
36
Cutter block assembly
1
77
Tensioner assembly
1
37
Ball bearing base assembly
2
78
Pin
1
38
Driven pulley
1
79
Long pin
1
39
Protective plate
1
80
Chain wheel IV
2
40
Cutter block
1
81
Driving roller
1
41
Blade locking block
3
82
Pressing rolle
1
42
Blade 250x30x30
3
83
Bush
4
43
Compression spring
6
84
Spring
4
44
Dust chute
1
85
Spring
1
45
Dust chute head
1
86
Connecting plate
1
