ADENDORFF ML392 - Page 28

２７
12”(ML393) PART LIST
NO.
SPECIFICATION
QTY
NO.
SPECIFICATION
QTY
1
Base stand
1
42
Blade 310x30x3
4
2
Motor base
1
43
Compression spring
8
3
Small cover plate
2
44
Dust chute
1
4
Right cover plate
1
45
Dust chute head
1
5
Support sleeve
1
46
Locking plate
1
6
Fixed plate
1
47
Change-over plate
1
7
Axle
1
48
Nut M6X12
2
8
Screw
1
49
Thicknesser table assembly
1
9
Bush
1
50
Lifting tube
1
10
Adjusting screw
1
51
Oriented body
1
11
Support base
4
52
splint
1
12
Right cutter block support
1
53
Gear case assembly
1
13
Left cutter block support
1
54
Mandril
1
14
Front adjusting block
1
55
Block
1
15
Back adjusting block
1
56
Block
1
16
Front locking block
1
57
Locking bar assembly
1
17
Back locking block
1
58
Wheel assembly
1
18
In-feed table
1
60
Pointer
1
19
Out-feed table
1
61
Depth scale
1
20
Adjusting axle
2
62
Washer
1
21
Apron
2
63
Thicknesser table
1
22
Locking handle assembly
2
64
Apron
4
23
Eccentric bush
2
66
Gear box
1
24
Screw M10x8
2
67
Helical gear
1
25
Kick block
15
68
Guide screw
1
26
Turning axle
1
69
Gear axle
1
27
Support axle
2
70
Bush
1
28
Nut M12
3
72
Double head screw
1
30
Feed scale
1
73
Locating bush
1
31
Adjusting wheel
2
74
Control handle assembly
1
32
Locating plate
1
75
Chain wheel assembly
1
33
Feed pointer
1
76
Chain wheel assembly
1
35
Hex bolt M12x55
2
77
Tensioner assembly
1
36
Cutter block assembly
1
78
Pin
1
37
Ball bearing base assembly
2
79
Chain wheel axle
1
38
Driven pulley
1
80
Chain wheel IV
2
39
Protective plate
1
81
Driving roller
1
40
Cutter block
1
82
Pressing rolle
1
41
Blade locking block
4
83
Bush
4
