CHARACTERISTICS:
The HD67643-A1 is a EtherNet/IP Master / PROFIBUS slave Converter.
It allows the following characteristics:
Two-directional information between EtherNet/IP and PROFIBUS;
Electrical isolation between PROFIBUS – EtherNet/IP, Power Supply – EtherNet/IP, Power Supply – PROFIBUS;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67643 software on your PC in order to perform the following:
Define the parameter of the PROFIBUS;
Define the parameter of the EtherNet/IP;
Define the list of EtherNet/IP slaves connected to the converter;
Update the device.
