TECHNICAL SPECIFICATIONS
Items
Specifications & Metrics
Module
LED Configuration
3-in-1 SMD 2020 LED
Pixel Pitch (mm)
4.8mm
Module Resolution (WxH)
104x103
Size (mm)
500x125
Weight (kg)
388g(PGBA)
Panel
Module Per Panel (WxH)
1x4
Panel Resolution (WxH)
104x103
Panel Size (mm)
500x500x73
Panel Area (m
2
)
0.25
Weight (kg/Panel)
5.7
Pixel Density
43264
IP Rating
IP50
Surface Flatness (mm)
Gaps±
Optical
Parameters
Brightness Before Correction (nit)
600~800
White Balance Brightness (nit)
800~1200
Color Temperature (k)
7000±3000K
Distance:
12.5ft. (3.8m)
Vertical Viewing Angle (°)
Horizontal 160° / Vertical 120°
Pixel Center Distance Deviation
<3%
Brightness Uniformity
≥97%
Brightness Adjustment
0~100% 100 Levels
Gray Scale / Display Color:
14 Bit
Color Uniformity
No more than ±0.003Cx, Cy
Contrast Ratio
3000:1
Electrical
Working Voltage
AC100~240V (50~60Hz)
Power Consumption
Max: 157.5W/panel Average: 52.5W/panel
Connections Power/Data
Power-Locking Power Connector In/Out; Data Locking RJ45
Ethernet Connector In/Out
Frame Update Frequency
50-60Hz
Driving Method
Constant Drive
Scan Mode
1/13 Duty
Frame Update Frequency
50-60Hz
Refresh Frequency (Hz)
≥1920Hz
Support Input
Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance
Ethernet Cable<100m, Fiber Optic>120m
Support VGA Mode
1024x768, 1280x1024, 1600x1200, & 1920x1280
Control System
Nova Star Synchronous System with Control via DVI
Environmental
and Usage
Parameters
Operating Life / MTBF
80,000 Hours / 10,000 Hours
Environment Temperature
Working temperature: -20°C-45°C
Storage Temperature: -30°-60°C
Environment Humidity
Working: 10-90% (No condensation)
Storage: 10-90% (No condensation
Out of Control Rate
<0.0003%
Environment Mode
Cat5
Angle of Arc Installation
165° - 195°
Minimum Circle Diameter (m)
3.8
Listings
CE, FCC, & ETL
Specifications subject to change without any prior written notice.
