Encore FR150z Layout
1
2
8
3 4 5 6 7
9
14
10 11 12 13
1516
1. Zoom Adjustment Knob
2. 3-Pin DMX In
3. 5-Pin DMX In
4. PowerCON In
5. Fuse
6. PowerCON Out
7. 5-Pin DMX Out
8. 3-Pin DMX Out
9. Mode Button
10. USB Port
11. Enter Button
12. LCD Menu Control Display
13. Down Button
14. Up Button
15. Barn Door Secure Lock
16. Gel Frame
